Description
The TD003G is a high-performance, well-balanced impact driver designed for efficiency in diverse fastening tasks. Built on the 40V Max XGT platform, it provides professional torque and features 4-stage impact selection along with specialized assist modes for wood and metal. This ensures fast driving without damaging materials.
- High-performance brushless motor for efficient fastening
- 4-stage impact power selection for application control
- Assist modes for controlled driving in wood and metal
- Compact and ergonomic design for reduced operator fatigue
- LED job light with afterglow function
Technical Data
| Max. capacities standard bolt | M5 – M16 |
| Max. capacities high tensile bolt | M5 – M14 |
| No load speed | Max.: 0 – 3,700rpm Hard: 0 – 3,200rpm Med: 0 – 2,100rpm Soft: 0 – 1,100rpm |
| Impact rate | Max.: 0 – 4,600ipm Hard: 0 – 3,600ipm Med: 0 – 2,600ipm Soft: 0 – 1,400ipm |
| Max. tightening torque | Max.: 220Nm Hard: 170Nm Med: 50Nm Soft: 20Nm |
| Drive shank | 6.35mm (1/4″) Hex |
| Overall length | 119mm |
| Skin weight | 1.0kg |
| Weight (with battery) | 2.0kg (BL4040) |
| Voltage | 40V Max |
Includes
- 1x TD003GZ 40V XGT Brushless Impact Driver (bare unit, no battery or charger)
- Belt hook assembly (346317-0 & 266622-8)
