Description

Z735M ZTrak™ Zero Turn Mower

• 25-hp (18.6 kW)*, 810 cc engine
• 48-, 54-, or 60-in. High-capacity PRO mower deck with welded deck reinforcements
• 22.5-in. seat with adjustable armrests, springs and ComfortGlide™ suspension
• Cut height adjustment dial adjusts mower in ¼-in. increments from 1.5 – 5 inches

• Smooth and powerful professional-grade V-twin engine for performance and long life

  High-capacity (HC) PRO Mower Decks offer superior cut quality and versatility

  Operator station is adjustable for superior comfort

  Seat includes ComfortGlide™ suspension and adjustable springs for a smooth ride

  Three-position, adjustable foot platform to accommodate different size operators

  	John Deere Z735M ZTrak™ Zero Turn Mower

   Export to Excel

  Key Specs

  Engine power	25 hp 18.6 kW
  Engine model number	HTR810
  Forward speed	0-9.5 mph 0-15.3 km/h
  Front caster tires	13×6.5-6
  Drive tires	23×9.5-12 (48-in. decks) 23X10.5-12 (54- and 60-in. decks)
  Seat back height	High back with adjustable armrests, 22.5 in. 57.1 cm
  Width of cut	48 in. 122 cm 54 in. 137 cm 60 in. 152 cm
  Mulching system	Optional MulchControl™ attachment
  Warranty	4 year/750 hour bumper-to-bumper* (*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at JohnDeere.com or JohnDeere.ca/Warranty for details.)

  Power	25 hp 18.6 kW
  Model number	HTR810
  Displacement	49.4 cu in. 810 cc
  Cylinders	V-twin
  Lubrication	Full pressure with replaceable filter, capacity, 2 U.S. qt 1.9 L
  Type	Overhead valve
  Battery	12 V 340 CCA
  Choke/speed control	Separate control levers
  Cooling method	Air
  Fuel tank capacity	8 U.S. gal. 30.2 L
  Fuel gauge	Fuel level sight line
